Black Diza curtain - pair
Black Diza curtain - pair
Product range code
404576
Description and parameters
For glass thickness up to 5mm. Fixing the glass with two diagonally placed screws. When the glass is fully inserted into the hinge, the distance between the edge of the glass and the edge of the hinge (side of the body) is 2 mm and from the bottom edge of the hinge (bottom of the body) 2.2 mm.
Parameters
Parameter | Value |
---|---|
Angle of opening | 180 |
Mounting into material | Screw |
