K-HETTICH WingLine S Pull2MS, 3 kg, 1200 mm, 6 hinges S, right+left, grey
Complete set of WingLine S Pull to move silent fittings for light doors of weight up to 3 kg, with right and left opening, including the opening mechanism. The door opens fully when handle is pulled to an angle of approx 35 °, the door closes softly. The set does not include a lower guide. For a wing of width 250 - 300 mm and height up to 1000 mm. For a cabinet of width max 1200 mm. Amount of hinges between the doors - 6 pcs. Holding hinge design: for screw fixing. Colour: grey. To be ordered separately -the recommended side hinges - see related assortment. Assembly instructions can be found on our website for each item of this set.
All product information and installation instructions can be found on the manufacturer's website here.
Available while stocks last at the supplier. Alternative/s provided.
Parameters
| Parameter | Value |
|---|---|
| Colour | Gray |
| Fill (mm) | 16 - 22 |
| Load capacity (kg) | 3 |
| Maximum leaf width (mm) | 300 |
| Orientation | Right+Left |
| Type | WingLine S Pull |
Composition of the set
| Title | Code | Quantity in set | Price excluding VAT | |
|---|---|---|---|---|
|
HETTICH 9283230 WingLine S Pull to move silent gray left | 409297 | 1 set | 8,01 EUR |
|
HETTICH 9283117 WingLine S Pull to move silent gray right | 409300 | 1 set | 8,01 EUR |
|
HETTICH 9238120 WingLine L/S Pull2MS mechanism for ligHETTICH doors gray left | 409279 | 1 set | 55,04 EUR |
|
HETTICH 9238119 WingLine L/S Pull2MS mechanism for ligHETTICH doors gray right | 409282 | 1 set | 55,04 EUR |
|
HETTICH 9283265 WingLine S shock absorber gray | 409309 | 2 pcs | 0,63 EUR |
|
HETTICH 9279130 WingLine S upper guide profile 1200 mm anodized aluminum | 409312 | 1 pcs | 13,96 EUR |
|
HETTICH 9278788 WingLine L folding curtains 2 pcs to press | 409246 | 2 set | 19,74 EUR |
Last visited
| Title | Code | Availability |
Divisibility/ packaging |
Basic price per unit | |
|
Set
Tips for getting a better price
Order the whole package and your price per pc (set) will be %price% |
536310 |
In stock
|
1 set / 1 set |
218,16 EUR
/ set
263,97 EUR incl. VAT
|
|
